CPU

RK3568，ARM Cortex A55，Quad-core，2 GHz

GPU

G52 2EE,OpenGL ES1.1/2.0/3.0/3.1/3.2, Vulkan 1.1, OpenCL 2.0

NPU

RK NN, 0.8Tops

Memory

Type

32-bit，LP4/LP4x

Capacity

2GB(Up to 8GB)

Display

VGA

1×Port

HDMI

1×HDMI Port, Up to 4K*2K Multiple Display

Storage

eMMC

Capacity 16GB(Up to 64 GB)

COM

Port Number

3

Mode

2×RS232（可配置為TTL），1×RS485

PWR

可選5V 供電

Ethernet

RJ45

10/100/1000Mbps

Wifi

AP6398S

802.11 b/g/n/ac, 2.4/5GHz

SDIO WIFI/BT MODULE-2T2R

Bluetooth

AP6398S

BT-V5.0 BLE

Expansion Slot

Mini_PCIe

1×PCIe2.0（4G Mode、PCIe2.0、mSATA）

1×PCIe3.0

Rear IO

1×DC_IN,DC12V/2A

1×SIM Slot(With card tray)

1×TF Card Up to 64 GB

1×USB2.0

1×USB3.0 OTG

6×RJ45 10/100/1000M LAN（Bypass：LAN3-4，LAN5-6）

1×HDMI

Internal Connector

1

1×VGA

1×SATA2.0

2×USB2.0

2×RS232，1×RS485

GPIO，8CH

2×TP port，I2C Interface

1×SATA

1組LAN LED插針

Mechanical & Environment

Dimension

203*146mm

PWR Input

DC12V

PWR Output

DC12V（ATX 4Pin接口）

Operation

-10~55℃，10%~90%RH，non-condensing

Storage

-40~75℃，5%~95%RH，non-condensing

OS

Android 11、Linux、OpenWrt、Debian
